Consew 318RK-1 Single Needle Drop Feed Lockstitch
with Edge Trimming Device,Reverse Stitching
Industrial Sewing Machine + Knockdown Stand








Features:
High Speed
Single Needle
Drop Feed
Lockstitch Machine
Edge Trimming Device
Automatic Lubrication System
Reverse Feed
Edge trimming device is located alongside the needle and is easily engaged or disengaged even during
the sewing cycle (push-button control)
Carbide tipped upper knife and tool steel lower knife
Trimming margin (distance from the needle to the knife) can easily be changed
A perfectly balanced mechanical system is used for the knife mechanism assuring vibration-free
operation with straight and uniform trimming

Specifications:
Max Speed: 4000 SPM
Max Stitch Length: 5 SPI (5 mm)
Clearance Under Foot: Hand 5/16" (8 mm), Knee 15/32" (12 mm)
Needle Bar Stroke: 17/32" (31 mm)
Needle: 16 × 257
Knife Stroke: 13/64" (5 mm)
Trimming Width, Max: 3/8" (9.5 mm)
Work Space: 10-1/8" (258 mm)
Uses: This machine is for stitching and simultaneous edge trimming. Stitching and trimming lapels,
shirt collars and cuffs, etc. For apparel of different weights ranging from light to heavy materials such
as cottons, knits, denim, polyester, nylon and sheer fabrics.

Included Accessories:
(1) Adjustable Steel K-Leg Stand with Table Top, Knockdown
(1) CS1000 Electronic DC Servo Brushless, Clutchless, 110V, 3/4hp, 600W, 0-5000RPM "Quite" Motor
(1) Motor Belt
(1) Drawer
(1) Knee Lift w/Pad
(1) Bobbin Winder
(1) 2 Spools Thread Stand
(1) Qt. of Clear Oil
(1) Set of Tools
(3) Needles & Bobbins
(1) Instruction Manual
Warranty Card

US Warranty: 1 year parts, 90 days labor on defects in materials and workmanship.
Non-US Warranty: 30 days parts and labor.


Availability: Yes

Condition: New in (4) Boxes

Shipping: This item usually leaves warehouses right after your purchase

Returns: See our Store Policy


Add to Cart





Sale Price$1,650.00
